Moxa EDS-205A-T Unmanaged Ethernet switch

Description

Moxa EDS-205A-T Unmanaged Ethernet switch

Introduction

The Moxa EDS-205A-T/208A series are 5 and 8-port industrial Ethernet switches that support IEEE 802.3 and IEEE 802.3u/x with 10/100M full/half-duplex, MDI/MDI-X auto-sensing. The EDS-205A/208A switches provide 12/24/48 VDC (9.6 to 60 VDC), 18 to 30 VAC redundant power inputs that can be connected simultaneously to live AC/DC power sources. These switches have been designed for harsh industrial environments, such as in maritime (DNV/GL) or hazardous locations (Class I Div. 2, ATEX Zone 2) that comply with FCC, TUV, UL, and CE standards.

The EDS-205A/208A switches are available with a standard operating temperature range from -10 to 60°C, or with a wide operating temperature range from -40 to 75°C. All models are subjected to a 100% burn-in test to ensure that they fulfill the special needs of industrial automation control applications. In addition, the EDS-205A/208A switches have DIP switches for enabling or disabling broadcast storm protection, providing another level of flexibility for industrial applications.

---

---

Features

• 10/100BaseT(X) (RJ45 connector), 100BaseFX (multi/single-mode, SC or ST connector)
• Redundant dual 12/24/48 VDC, 18 to 30 VAC power inputs
• IP30 aluminum housing
• Rugged hardware design well suited for hazardous locations (Class I Div. 2 /ATEX) and maritime environments (DNV/GL)
• -40 to 75°C operating temperature range (T models)

Ethernet Interface

10/100BaseT(X) Ports (RJ45 connector)

• EDS-205A/ Moxa EDS-205A-T : 5
• EDS-205A-M-SC/M-ST/S-SC Series: 4
• All models support:
• Auto negotiation speed
• Full/half duplex mode
• Auto MDI/MDI-X connection

1. 100BaseFX Ports (multi-mode SC connector) :EDS-205A-M-SC Series: 1
2. 100BaseFX Ports (multi-mode ST connector) :EDS-205A-M-ST Series: 1
3. 100BaseFX Ports (single-mode SC connector) :EDS-205A-S-SC Series: 1

Standards

• IEEE 802.3 for 10BaseT
• IEEE 802.3u for 100BaseT(X) and 100BaseFX
• IEEE 802.3x for flow control

Switch Properties

• MAC Table Size : 1 K
• Packet Buffer Size :384 k-bits
• Processing Type :Store and Forward

Power Parameters

Connection : 1 removable 4-contact terminal block(s)

Input Current

• EDS-205A/Moxa EDS-205A-T : 0.09 A @ 24 VDC
• EDS-205A-M-SC/M-ST/S-SC Series: 0.1 A @ 24 VDC

Input Voltage : 12/24/48 VDC, Redundant dual inputs
Operating Voltage : 9.6 to 60 VDC
Overload Current Protection :Supported
Reverse Polarity Protection :Supported

DIP Switch Configuration

Ethernet Interface :Broadcast storm protection

Physical Characteristics

• Housing : Aluminum
• IP Rating : IP30
• Dimensions : 30 x 115 x 70 mm (1.18 x 4.52 x 2.76 in)
• Weight : 175 g (0.39 lb.)
• Installation : DIN-rail mounting, Wall mounting (with optional kit)

Environmental Limits

Operating Temperature
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature (package included) : -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity : 5 to 95% (non-condensing)

Warranty

Warranty Period : 5 years

Package Contents

Device : 1 x Moxa EDS-205A-T Series switch

Documentation

• 1 x quick installation guide
• 1 x warranty card.

Additional information

Brand	Moxa
Product ID	EDS-205A-T
Processing Type	Store and Forward
Connection	1 Removable 4-contact terminal block(s)
Ethernet Interface	Broadcast storm Protection
Housing	Aluminum
IP Rating	IP30
Dimension	30 x 115 x 70 mm (1.18 x 4.52 x 2.76 in)
Warranty	5 Years.
