Eaton Environmental Monitoring Probe Gen 2 EMPDT1H1C2

Description

EMPDT1H1C2 Eaton Environmental Monitoring Probe Gen 2

The New Environmental Monitoring Probe (EMP) Gen 2 (EMPDT1H1C2), is a second-generation environmental monitoring probe. The new EMP maintains all the functionality of the previous generation of sensors (temperature, humidity and dry-contact monitoring) while adding the ability to be daisy-chain (up to 3 per host), allowing multiple sensor connection to a single host.

This enhances the richness of rack level environmental data for the top, middle and bottom of the rack. Temperature, humidity, and contact status can be viewed with a Web browser through the Network user interface. Hot-swap feature simplifies installation to enable you to install the probe without turning off the power to the device or to the loads that are connected
to it. The EMP monitors the status of the two user provided contact devices and can be located 50m from the network card using standard CAT5 network cable. The probe comes with a screw and screw anchor, nylon fasteners, tie wraps, and magnets.

GENERAL SPECIFICATIONS

Product Name : Eaton UPS environmental monitoring probe

Catalog number : EMPDT1H1C2

UPC : 743172091604

Product Length / Depth : 27 mm

Height : 15.5 mm

Product Weight : 0.28 kg

Compliance : CE Marked

Certifications : CE

PRODUCT SPECIFICATION

Type : Environmental Monitoring Probe ( EMP )

Connection : Wired + Dry contacts

Type of Detector : Temperature / Humidity

Type of accessory / spare part : Other
