Teltonika RUT950 LTE Router | Industrial 4G LTE Wi-Fi router

Description

Teltonika RUT950 LTE Router | Industrial 4G LTE Wi-Fi router

Teltonika RUT950 is a high-performance industrial 4G LTE Wi-Fi router designed as a Main/Backup internet source and guarantees a reliable internet connection with high data throughput and data redundancy.

Compatible with the Teltonika Networks Remote Management System (RMS) for easy and secure monitoring.

It has four Ethernet ports, two external SIM holders, digital I/O, and signal strength status LED indicators.



RUT950 is a compact industrial 4G (LTE) router equipped with 4x Ethernet ports, WiFi, Dual-SIM and RutOS software for advanced networking solutions.

CONNECTIVITY: 4G/LTE (Cat 4), 3G, 2G

WAN FAILOVER: Automatic switch to available backup connection

WIFI: Wireless Access Point with Hotspot functionality

DUAL SIM: With auto failover, backup WAN and other switching scenarios

ETHERNET: 4x Ethernet interfaces with VLAN functionality

RMS: Compatible with Teltonika Remote Management System



CONNECTIVITY

4G/LTE (Cat 4), 3G, 2G

WAN FAILOVER

Automatic switch to available backup connection

WIFI

Wireless Access Point with Hotspot functionality

DUAL SIM

With auto failover, backup WAN and other switching scenarios

ETHERNET

4x Ethernet interfaces with VLAN functionality

RMS

Compatible with Teltonika Remote Management System

Front view

No.	Description
1	LAN Ethernet ports
2	WAN Ethernet port
3	LAN LEDs
4	WAN LED
5	Power socket
6	Power LED
7	Mobile connection status LED
8	Mobile signal strength indication LEDs



Back view

No.	Description
1	LTE antenna connectors
2	WiFi antenna connectors
3	Reset button
4	SIM card slots



Connectors

Power Socket Pinout
No.	Description	Wire color
1	Power	Red
2	Ground	Black
3	I/O	Green
4	I/O	White



Additional information

Mobile module	4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps
SIM switch	2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
Wireless mode	IEEE 802.11b/g/n, Access Point (AP), Station (STA)
WiFi users	Up to 100 simultaneous connections
Ethernet	1 x WAN port (can be configured to LAN) 10/100 Mbps, comply IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX 3 x LAN ports, 10/100 Mbps, comply IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
Routing	Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, NHRP)
Input voltage range	9 – 30 VDC
Operating temperature	-40 °C to 75 °C
