Eaton 9SX 3000I 3000VA 2700W Tower On-line double conversion with PFC System 9SX3000I

Description

Eaton 9SX 3000I 3000VA 2700W Tower On-line double conversion with PFC System 9SX3000I, Input: C20, Outputs: (8) C13, (1) C19

Buy Eaton 9SX 3000I 3000VA 2700W Tower On-line double conversion with PFC System 9SX3000I best price in Dubai UAE | Input: C20, Outputs: (8) C13, (1) C19

Online double conversion UPS
Successor of Eaton 9130 UPS

General
Topology	On-line double conversion with PFC (Power Factor Correction) system
Configuration	Tower
Part Number	9SX3000I
Rating (VA/Watts)	3000/2700
Dimensions (H x W x D, mm)	346 x 214 x 412
Warranty	2 years warranty

Electrical Input
Connection	(1) IEC-320-C20
Input Voltage Range	200-276V without derating (up to 140-276V with derating)
Nominal Voltage	200/208/220/230/240V
Frequency	50/60 Hz autoselection
Frequency Range	40-70 Hz



Electrical Output
Outlets	(8) IEC-320-C13 (1) IEC-320-C19
Output Frequency	50/60 Hz autoselect, frequency converter as standard



Communications
User Interface	Multilingual graphical LCD display
Communication Ports	1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote Power Off + 1 mini-terminal block for Output relay
Communication Slot	1 slot for Network-M2, Network-MS, ModBus-MS or Relay-MS cards



Environmental & Standards
Audible Noise	<45dB
Operating Temperature	0 to 40°C continuous
Safety markings	IEC/EN 62040-1, UL 1778, CSA 22.2
EMC Markings	IEC/EN 62040 -2 , FCC Class B, CISPR22 Class B
Approvals	CE /CB report (TUV) / cULus / EAC / RCM / BIS / KCC



ADDITIONAL SPECIFICATIONS

FORM FACTOR: Tower

CONSTRUCTION TYPE: Free standing model

RACK MOUNTING KIT: No

EFFICIENCY: 92.4

PACKAGE CONTENTS

9SX UPS
Input cable
2 IEC output power cords
USB Cable
Serial Cable
Safety guide
QuickStart

PHASE (INPUT): 1

PHASE (OUTPUT): 1

INTERNAL BYPASS: Yes

HOT SWAP POWER: No

AUTO SHUTDOWN FUNCTION: Yes
