APC SMC3000I Smart-UPS C 3000VA LCD 230V-TOWER

Description

APC SMC3000I Smart-UPS C 3000VA LCD 230V-TOWER

INTRODUCTION

APC SMC3000I is part of the Smart-UPS range, an intelligent and efficient network power protection offer from entry-level to scalable runtime. This 3000VA/2100W line-interactive UPS provides pure sinewave power to support critical electronics during power disruptions. The tower mount SMC operates in green mode for high operating efficiency. It comes with IEC 320 C20 input, 8x IEC 320 C13 and 1x IEC 320 C19 outlets. This UPS has built-in lead-acid battery and is covered by a 2-year UPS warranty. Its dimensions are 544mm (depth) x 435mm (height) x 197mm (width) and weighs 43.0kg. Ideal for entry-level servers, networks, business VoIP, retail point-of-sale, edge networks and business desktops. It conforms to CE, C-Tick, GOST, EAC, SABS and VDE.

Specifications

Presentation : Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Lead time : Usually Ships within 2 Weeks

Main / APC SMC3000I

• Main Input Voltage : 230 V
• Other Input Voltage
  220 V
  240 V
• Main Output Voltage : 230 V
• Rated power in W : 2100 W
• Rated power in VA : 3000 VA
• Product or component type : Uninterruptible power supply (UPS)
• Input Connection Type : IEC 320 C20
• output connection type / APC SMC3000I
  8 IEC 320 C13
  1 IEC 320 C19
• Number of rack unit : 0U
• Battery type : Lead-acid battery
• Provided equipment
  CD with software
  Documentation CD
  USB cable

Batteries & Runtime

• Extended runtime : 0
• Number of battery filled slots : 0
• Number of battery free slots : 0
• Battery recharge time : 3 h
• Number of battery replacement quantity : 1
• Battery life : 3…5 year(s)
• Battery charger power : 183 W rated

General / APC SMC3000I

• Number of power module filled slots : 0
• Number of power module free slots : 0
• product web sub-family : Entry level
• Redundant : No

Physical

• Color : Black
• Height : 43.5 cm
• Width : 19.7 cm
• Depth : 54.4 cm
• Net weight : 43 kg
• Mounting location : Front
• Mounting preference : No preference
• Mounting mode : Not rack-mountable
• Two post mountable : 0
• USB compatible : Yes

Input / APC SMC3000I

• Input voltage limits
  170…300 V adjustable
  180…287 V
• Network frequency : 47…63 Hz

Output

• Harmonic distortion : Less than 5 % at full load
• Maximum configurable power in VA : 3000 VA
• Maximum configurable power in W : 2100 W
• UPS type : Line interactive
• Wave type : Sine wave
• Output frequency : 50 Hz sync to mains

Conformance / APC SMC3000I

• product certifications
  C-Tick
  CE
  EAC
  GOST
  SABS
  VDE
• Standards
  EN/IEC 62040-1:2019/A11:2021
  EN/IEC 62040-2:2006/AC:2006
  EN/IEC 62040-2:2018

Communications & Management

• Control panel : Multifunction LCD status and control console
• Free slots : 0
• Alarm : Alarm when on battery : distinctive low battery alarm : configurable delays.

Surge Protection and Filtering / APC SMC3000I

• Surge energy rate : 300 J
• Noise suppression : Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Contractual warranty

• Warranty : 2 years repair or replace.

Additional information

Brand	APC
Part Number	SMC3000I
Nominal output voltage	230 V
Battery type	Lead-Acid Battery
Output Connection Type	8 IEC 320 C13 1 IEC 320 C19
Battery Recharge Time	3 Hours
Dimensions ( H x W x D in cm)	43.5 cm x 19.7 cm x 54.4 cm
weight	43 kg
Wave Type	Sine Wave
